XBSL vertical sand pump is mainly used for laboratory conveying the pulp and tail mine coal preparation plant, and can also be used for conveying medium, aluminum easy to transport high-temperature crystallization slurry and cement plant feeding material, this product by the former Ministry of geology only designated production enterprise, the implementation of industry standards.
XBSL vertical sand pump is composed of pump body, bearing seat, vertical shaft is fixedly connected the impeller to rotate in a rolling bearing. Both ends of bearing and rolling bearing is a pressing, also must be sealed bearing lubricating oil without leakage, the pump body is arranged on the bracket of the motor and the motor, the triangle belt drive the rotation of the impeller in the pump chamber, the impeller pressure to force out slurry. In order to prevent the sand into the bearing in the spindle is equipped with a centrifugal wheel.
